The Kappa's Izakaya: 360° Illustration Process

Recently I worked on a 360° illustration of an Izakaya in Daryl Qilin Yam's Kappa Quartet and I was asked if I could share a bit more about the process of doing such an illustration.

Artistic disclaimer: It just so happened that I watched a lot of Midnight Diner at the time when I was doing this illustration, so those spaces were definitely in my mind's eye. There was also the show Samurai Gourmet which was a bit tiresome to watch, but had a few good shots of a traditional izakaya too. Alas, although I have visited Tokyo several times before, at this point I haven't really been to a bar or izakaya in some years now...


From "Midnight Diner: Tokyo Stories"

From "Samurai Gourmet"
Some things I realised from these portraits of izakayas is that when in doubt on how to fill the bar space, you can put stacks of tiny crockery or cover it up with a cupboard!


I even made a little crackleware... not that the detail is visible in the final render
Another disclaimer: Where 3D modelling is concerned, I mainly design spaces and architectural/interior renders and I'm not a character designer! This will probably be apparent to people who actually do proper animation / character design because here I chose to render all the other people in the scene in this weird white low-poly form. Personally I thought it a good fix for my weakness and also that it kinda worked for this 'horror' piece...

Initially I thought that I would actually try to do the entire drawing by hand because I have actually enjoyed doing similar illustrations entirely by hand in the past - especially with lens distorsion like this:


2 illustrations from the set of 4 that I was commissioned to do for the Commuting Reader
I usually work out a lot of the alignment for this kind of illustration by doing a 3d model using a fisheye or panoramic lens. After arranging white blocks in the space and rendering it out, I just use those lines in the render as perspective reference for my drawing.


Example: this plain equirectangular render with no materials...
And for all other details that you need to fill in by hand, you can rely on an equirectangular grid (here is a link to an equirectangular grid by David Swart that you can use as a template) and think of it as a 4 point perspective drawing as so:



Here's a 4 hour sketch I made using the grid for the fun of it in 2018...
(Back when I had a lot of free time huh)





Problem right now is that feeding and caring for Beano made it extraordinarily difficult for me to be able to use the tablet or cintiq. If left to her own devices, she wants to pull on all the type-c cables and gnaw on my stylus and then slap my cintiq screen! Attempts to set up my workstation in the bedroom so I can use the cintiq when she's asleep have failed in baby safety. In fact I've more or less resigned myself to the fact that spending time with the tablet is impossible now - WHO WANTS TO BUY A MEDIUM WACOM AND/OR A CINTIQ PRO IN EXCELLENT CONDITION??? - and I've had to streamline my time spent designing, thinking of the fastest way to get the visual output. Hours spent doing digital painting like in the old days? Not happening anymore. A blender render is all I can muster now, which is great because whilst I feed and entertain Beano, I can easily set a render going so that I feel as if my illustration is partly doing itself whilst I'm busy...



I also use a renderfarm to speed things up a bit and I usually do a smaller resolution render to check that things are alright before doing the full size. At the 50% of the resolution I wanted it cost about 40-60 US cents (0.85 SGD) for each one. For the final render at 100% resolution and twice the samples, it cost about 4 USD (5.60 SGD).



I don't know how most people do the next step but I usually go through a process of annotating my renders and then ticking them off in Monosnap through as I do the edits:





Finally we end up with the base render onto which I can add faces and other details in Photoshop. I do find that adding a bit of noise (0.5%-2%) also helps make it more 'painterly' because when the render is too sharp it becomes a bit disconcerting and unreal. I also drop the file periodically into this equirectangular viewer to see if the work is shaping up correctly - usually common issues might include (1) some things in the image that seemed further away may suddenly seem extremely close to the camera view or (2) items may be blocked when you render the specific view - so some time needs to be spent finetuning the arrangement.


Render Breakdown
This was another work made possible by the Dingparents who came down to take care of Beano on the weekends so I could continue my artistic pursuits! I am grateful to have the time to continue to make my work.

---

Come see the final image at Textures: A Weekend of Words, at Sorta Scary Singapore Stories by Tusitala.



13 - 22 Mar
10am – 10pm
The Arts House

Textures: A Weekend of Words celebrates Singapore literature and its diverse community. No longer a solitary experience, reading becomes a shared adventure through performances, installations, and workshops that will take you on a trip through the literary worlds of local authors.

The third edition of the festival takes on the theme “These Storied Walls”. Inspired by The Arts House’s many identities as a Scotsman’s planned estate, our nation’s first parliament, and now Singapore’s literary arts centre, the walls of The Arts House have been etched with the stories of those who have walked these halls.

This year’s programming features more installations and participatory activities that invite you to go a step further — move a bit closer and look a little longer. As you discover undiscovered narratives of your own, join those who have come before and weave your story into the tapestry of The Arts House.

Textures is co-commissioned by The Arts House and #BuySingLit, and supported by National Arts Council

More about Sorta Scary Singapore Stories

Paintpusher: Computer-aided Oil Painting (SUPER–TRAJECTORY: Life in Motion, ArtScience Galleries, 20 February to 8 March 2020)

Behold! This is a painting made by me and a little XY plotter which pushes the paint around. (I originally gave it a title with the word "sketches" in it because I like how it starts from a pencil sketch, to a processing sketch, then to this plotter's wonky sketch that pushes paint around on the canvas... but now thinking about it, I am actually thinking I should rename the work to "Paintpusher" because it is not really painting, it is really just pushing the oil paint around on the canvas...)

Every once in a while I get gripped by a desire to teach myself how to paint hyperrealistic or photorealistic -- just for the hell of it and being able to master it...? - but then I realise it will take me years of muddling along in the good old fashioned, humans-doing-oil-paintings-by-hand sort of way. Additionally, my own approach for understanding and making visual work has always been via the digital, so instead of mucking around helplessly in oils, I thought I would try to do a little "computer-aided oil painting"...

Doing 'precision' painting of any sort is messy and potentially very time-consuming, and now with a Bean to feed and care for (practically a 24hr job), carving out time to make art has been much more challenging (in addition to my teaching day job). Whilst spending long hours breastfeeding Beano, I had quite a lot of time to plot and scheme up things, but I only had rigidly fixed windows of time where I could personally execute the program (ie: when my parents were available to take care of Beano on the weekends). In theory, I thought that by devising a process for making the 'precise' paintings (and sticking to the process!) it would help me control the amount of time I was spending on "Debbiework"... although the prep work takes the longest in that case. This painting experiment would not have been possible without my parents coming down over a few weekends to help care for Beano whilst I made a big painterly mess.

---

The Mini Line-Drawing Machine

Line-Us Concept Image
Some time back there was a kickstarter for a little drawing machine called the Line-Us, which they rather pointedly emphasised on their promotional material as being "NOT A TOY". Well then, what is it exactly? I guess it is a small usb powered plotter in which you can insert a pen and have it trace out an SVG file (you can also muck around by hand on their app and see how it partially messes up your drawing. There was also a concept gif they released, imagining it doing water colours.


Line-us plotting some random SVG that I made in Illustrator
The app that comes bundled with the Line-us allows you to draw on your mobile screen to control the Line-us. IT allows you to take a photo, put it in the background, and then you can trace over the image your self. Which ultimately produces something which is not dissimilar to something you might choose to draw with your non-dominant hand.

I've got to say that drawing on my phone to control Line-us's pen doesn't really seem like the point of having a device like this. I mean it makes for hilarious results from this NON-TOY, but it makes more sense as a SVG plotter, which I'm surprised isn't the function of its main app. Maybe they dont want to get your hopes up of it being able to plot perfect squares and perfect circles... BECAUSE IT DOESN'T. I used this script contributed by another user (Set the IP to 192.168.4.1 and it will connect the Line-US when in red mode)

The joy of the plotter is really in its "shonky-ness". It gets more and more askew as we progress further away on both axes. It wobbles and trembles and if your pen is tilted on an angle, the distortion from the tilt will become more and more pronounced at the extremes of the drawing board. One of the prominent apps touted for this "NOT-A-TOY" is a game where it will draw something (somewhat badly) and you have to guess what the Line-Us is trying to draw...

Painting Process


Initial Sketches
I started with some sketches of possible approaches. I had lofty dreams of doing a landscape painting at first, but in reality I don't have that much control (or rather it feels like youre in a constant state of almost losing control of the pen), and I found that with this kind of work, less is more. The more you push paint around, the more it looks like an indistinct mushy grey. Like if you smeared your face over a palette.


Line-us Manual Control - painted too long until paint became muddy
This is the mess it makes when you "overpush" the paint (output now discarded). Using manual control on the app meant that it was no different from me being an exceptionally incompetent painter. The process needs to be rigorously followed for this experiment to be meaningful, and I knew by this point that I wanted to make iterative paintings...


Processing Sketch
Referring to some of my pencil sketches, I wrote a Processing sketch to produce the drawing. I had more intentional and complex sketches at first, but as you can see, I ended up with something exceedingly basic. A super basic bezier. To be honest, everything more complicated just didn't make a good painting.

In Processing, you can use beginRecord to echo the drawing processes to a svg or pdf file. It generates an SVG file which comprises of the lines I drew with the code...


SVG Generated in Processing
And the SVG file is also readable by the plotter as a series of lines of coordinates which when joined up make the drawing.



The plotter outputs look a bit wonky, but the wonky-ness is consistent. If you made the Line-Us repeat the SVG, it would always outline over that same point, over and over again. So... it is very precisely inaccurate.





After testing out all the outputs, I prepared the canvas by using a palette knife to lay down a base colour that the plotter would paint over. I also experimented with using masking tape to mask out the area where I would be painting - I think the framing was crucial to the work looking as it does; without the framing, it just felt like a big messy paint blob; similarly without repetition one may not realise this is an iterative work or a work produced by a machine repeating an action over and over again.





After generating these tiny prints, I decided to digitise and blow up a set of 4 of them. I was originally only going to blow up one of them, but the output was better than I expected, almost resembling the fronds of a palm, with an organic form.



Initially I was going to get a normal photographic paper print when I happened to see at the printers how well the metallic prints seemed to bring out the colour, giving it more three-dimensionality. So... I decided to try doing my print on metallic and I love it!





The work is currently at ArtScience Museum, Level 4 until 9 March 2020. There wasn't an opening event due to coronavirus cancellations. But come and see it when you can and let me know what you think of them. And as for next steps, I think I will build a bigger XY plotter!...

---
